KIP 7900 Parts & Supplies

The KIP 7900 is a premier high-speed monochrome wide format multifunction system designed for the most demanding enterprise environments and high-volume production hubs. Delivering a rapid 13 'D' size (24" x 36") prints per minute, it features KIP's Advanced HDP Plus imaging technology to provide stunningly crisp text and high-definition fine lines with exceptional consistency. The 7900 is distinguished by its production-level durability and its standard 4-roll media capacity, Providing an immediate hub for continuous document production without frequent intervention. Featuring a sophisticated touch screen interface and 100% toner efficiency, the KIP 7900 serves as an indispensable workplace hub for producing professional-quality technical drawings, blueprints, and maps with surgical precision and production-level throughput in high-traffic production environments.

Core Performance Specifications

• Device Type: High-Volume Wide Format MFP (Print, Copy, Scan Standard)
• Print Speed: Up to 13 'D' size prints per minute (approx. 32 feet per minute)
• Print Resolution: 600 x 600 dpi (HDP Plus technology)
• Warm-up Time: Instant from standby
• Imaging Technology: KIP Electrophotographic LED
• Monthly Duty Cycle: Up to 100,000 linear feet
• Memory/Storage: 2 GB RAM Standard / 160 GB HDD Standard

Paper Handling and Media

• Standard Media Capacity: 4 Rolls (Integrated automatic roll switching)
• Maximum Roll Width: 36 inches (914 mm)
• Roll Length: Up to 500 feet per roll
• Media Types: Bond, Vellum, Film, and Waterproof media
• Efficiency: 100% Toner Efficient closed-loop system (Zero waste toner)
• Finishing Options: Modular support for KIPFold and high-capacity automatic stackers

Scanning and Digital Capture

• Scan Speed: Up to 12 ipm (B&W) / 6 ipm (Color) at 200 dpi
• Scan Resolution: Up to 600 dpi (Optical)
• Send Destinations: Scan-to-File, Email, FTP, Cloud (via KIP Cloud Connect)
• File Formats: TIFF, PDF, DWF, JPEG, CALS
• User Interface: High-definition touch screen with real-time image viewing

Connectivity and Security

• Network Interface: Ethernet 10/100/1000 Base-T (Standard)
• Printer Languages: Standard HP-GL/2, HP-RTL, TIFF, PDF, DWF
• Security: Standard HDD Encryption, Secure Data Overwrite, and User Authentication
• Management Tools: KIP System K software suite for web-based fleet management

Physical Dimensions

• Width: 1,245 mm (49.0 in.)
• Depth: 711 mm (28.0 in.)
• Height: 1,499 mm (59.0 in.)
• Weight: Approximately 350 kg (772 lb)
• Status: Leading-edge high-speed wide format hub for AEC production
