Konica Minolta PC405 Parts & Supplies

The Konica Minolta PC-405 is a high-density Large Capacity Cassette (LCC) designed to provide a massive 2,500-sheet paper reservoir for mid-volume bizhub multifunction printers. Unlike universal cabinets, the PC-405 features a single large drawer optimized for high-speed feeding of standard A4 or Letter-sized paper. This accessory is specifically engineered for departments with high-volume monochrome or color printing needs, effectively tripling the standard on-board paper supply. By minimizing the frequency of paper refills, the PC-405 ensures maximum uptime and a more efficient workflow for organizations producing long reports, manuals, and standard office documents.

Core Performance Specifications

• Accessory Type: 1-Drawer Large Capacity Paper Cabinet (Floor-standing)
• Total Capacity: 2,500 sheets (based on 80 g/m² paper)
• Supported Paper Size: A4 or 8.5" x 11" (Fixed)
• Paper Weight Support: 60 to 256 g/m²
• Feeding Technology: Advanced multi-roller high-speed feed system
• Primary Compatibility: bizhub C203, C253, and C353 series

Physical Design and Integration

• Workflow Optimization: Designed for high-volume, standard-sized document production
• Capacity Monitoring: Integrated level sensors communicate with the bizhub interface for real-time status
• Stability: Rugged industrial design serves as the primary floor stand for the MFP
• Access: Easy-pull drawer with high-capacity lift mechanism for rapid loading

Physical Dimensions

• Width: 570 mm (22.4 in.)
• Depth: 595 mm (23.4 in.)
• Height: 285 mm (11.2 in.)
• Weight: Approximately 29 kg (64 lb)
• Power Source: Provided by the main bizhub power supply
