Ricoh Aficio 2016 Parts & Supplies

The Ricoh Aficio 2016 is a versatile 16 ppm monochrome digital multifunction system designed for small-to-mid-sized workgroups requiring a reliable hub for rapid document production. Delivering a consistent 16 copies per minute, it features a fast 6.5-second first-copy time and standardizes high-resolution 600 dpi imaging. The Aficio 2016 is built on a compact modular chassis that supports media up to 11" x 17" (A3), making it ideal for Producing professional reports, manuals, and document sets. While designed as a robust digital copier, its modular architecture allows for the easy field-addition of network printing, scanning, and faxing modules as business needs grow. Utilizing Ricoh's sophisticated laser imaging technology and supporting multiple finishing options—including an internal 500-sheet stapler—the Aficio 2016 provides a scalable and cost-effective platform for monochrome document management with exceptional text clarity and engine uptime.

Core Performance Specifications

• Device Type: Small Workgroup Monochrome MFP (Copy Standard; Print/Scan Optional)
• Print/Copy Speed: Up to 16 ppm (A4/Letter) / 10 ppm (A3/Ledger)
• Resolution: 600 x 600 dpi
• First Copy Out Time: Approximately 6.5 seconds
• Monthly Duty Cycle: Up to 15,000 pages
• Warm-up Time: Approximately 15 seconds
• Memory/Storage: 16 MB RAM Standard (Max 384 MB with optional modules)

Paper Handling and Media

• Standard Paper Capacity: 350 sheets (1 x 250-sheet universal Tray + 100-sheet Bypass)
• Maximum Paper Capacity: Up to 1,350 sheets with optional units
• Document Feeder: Optional 30-sheet or 50-sheet Automatic Document Feeder (ADF)
• Media Sizes: A5 up to A3 (up to 11" x 17" Ledger)
• Paper Weight: 16 to 24 lb. Bond (Trays); up to 42 lb. Bond (Bypass)
• Duplexing: Manual (Standard); Automatic (Optional via hardware upgrade)

Copying and Image Features

• Imaging Technology: Single laser beam scanning & electro-photographic printing
• Copy Features: Electronic sorting (with optional memory), N-up copying (2-in-1, 4-in-1), and image rotation
• Zoom Range: 50% to 200% in 1% increments
• Modular Finishing: Supports optional 500-sheet internal finisher with stapling
• User Interface: Intuitive control panel with dedicated function keys and status indicators

Connectivity and Security

• System Architecture: Modular design for field upgrades
• Optional Upgrades: Network Printer Kit, Scanner Kit (B&W), Fax Unit
• Network Interface: 10/100BaseTX Ethernet (with printer kit), USB 2.0
• Security: Standard user code tracking for volume monitoring
• Management Tools: Web Image Monitor and SmartNetMonitor support

Physical Dimensions

• Width: 550 mm (21.7 in.)
• Depth: 568 mm (22.4 in.)
• Height: 420 mm (16.5 in.) (Main Body)
• Weight: Approximately 35 kg (77.2 lb)
• Environmental: Energy Star certified; designed for energy-efficient office operation
