Ricoh Pro C720 Parts & Supplies

The Ricoh Pro C720 is a high-performance digital color production system designed for print-for-pay environments, commercial print shops, and central reprographics departments (CRD). Delivering a robust 72 ppm in both color and monochrome, it was engineered as a high-fidelity digital press capable of producing professional-grade marketing materials, complex reports, and full-bleed 11" x 17" documents. Utilizing advanced PxP polymerized toner and featuring a true 1200 x 1200 dpi resolution, the Pro C720 provides exceptional image quality with consistent color fidelity across long production runs. Built on a heavy-duty engine, this system offers professional-grade reliability and extensive modular finishing capabilities, making it an ideal solution for high-impact in-house publishing and short-run color production.

Core Performance Specifications

• Device Type: Digital Color Production Press (Print Only)
• Print Speed: 72 ppm (Full Color and Monochrome)
• Print Resolution: 1200 x 1200 dpi
• First Page Out Time:
  • Color: 7.6 seconds
  • Monochrome: 6.0 seconds
• Monthly Duty Cycle: Up to 320,000 impressions
• Warm-up Time: Less than 300 seconds (5 minutes)

Paper Handling and Media

• Standard Paper Capacity: 2,500 sheets
• Maximum Paper Capacity: Up to 11,000 sheets with optional Large Capacity Trays (LCT)
• Feeding Technology: Professional air-assist paper feeding system prevents multi-feeds on heavy and coated stock
• Media Sizes: Up to 13" x 19.2" (SRA3) for full-bleed layouts
• Paper Weight: 16 lb. Bond to 110 lb. Cover (approx. 60–300 g/m²) at full engine speed
• Duplexing: Standard automatic duplexing (up to 300 g/m²)

Image Processing and Finishing

• Toner Technology: PxP Polymerized Toner for finer particles and high color fidelity
• Controller Options: Choice of integrated GWNX controller or advanced external EFI Fiery controllers
• TCRU System: Trained Customer Replaceable Units allow operators to replace key components without waiting for a technician
• Production Finishing:
  • Saddle-stitch booklet maker with edge trimming
  • High-capacity 5,000-sheet stackers with trolley carts
  • Z-folding and multi-hole punching units
  • Post-engine cover insertion

Connectivity and Security

• Network Interface: Ethernet 10/100/1000 Base-T, High-speed USB 2.0
• Supported PDLs: PCL 5c/6, Adobe PostScript 3, PDF 1.7, XPS
• Security: Standard HDD Encryption, Data Overwrite (DOSS), and IP Filtering
• Power Requirements: 208V - 240V, 24A (Requires dedicated production outlet)

Physical Dimensions

• Width: 1,089 mm (42.9 in.)
• Depth: 1,100 mm (43.3 in.)
• Height: 1,440 mm (56.7 in.) (Main body)
• Weight: Approximately 700 kg (1,543 lb)
• Industrial build: Engineered for sustained 24/7 reliability in professional settings
