Ricoh Pro C751EX Parts & Supplies

The Ricoh Pro C751EX is a flagship digital color production system engineered to deliver unmatched productivity and professional-grade image quality for the most demanding commercial print shops and large-scale corporate data centers. Delivering a blistering 75 pages per minute in both color and monochrome, it represents the pinnacle of performance in its series. The C751EX features Ricoh's innovative 4800 dpi VCSEL imaging technology and advanced PxP polymerized toner, Producing surgical precision in text and high-definition graphics with exceptional consistency. Built on a production-class chassis with a 350,000-page monthly duty cycle and support for professional in-line finishing—including saddle-stitch booklets, multi-folding, and professional GBC punching—the Ricoh Pro C751EX serves as an indispensable powerhouse for Producing professional-quality marketing collateral, catalogs, and transactional documents with unmatched speed and reliability in the digital production environment.

Core Performance Specifications

• Device Type: Digital Color Production Press (Print, Copy, Scan)
• Print/Copy Speed: 75 ppm (Full Color and Monochrome)
• Print Resolution: 1200 x 4800 dpi (VCSEL Technology)
• Max Monthly Volume: Up to 180,000 pages
• Duty Cycle: Up to 350,000 impressions
• Memory/Storage: 2 GB RAM / 320 GB HDD Standard

Paper Handling and Media

• Standard Paper Capacity: 2,500 sheets
• Maximum Paper Capacity: Up to 7,000 sheets with optional Large Capacity Trays (LCT)
• Media Sizes: Up to 13" x 19.2" (Maximum media size); supports banner printing up to 630 mm
• Paper Weight: 14 lb. Bond to 110 lb. Cover (52.3 to 300 g/m²)
• Efficiency: Designed for continuous-run reliability with high-capacity consumables and "on-the-fly" replenishment

Scanning and Image Processing Features

• Scan Resolution: Up to 600 x 600 dpi
• TCRU System: Trained Customer Replaceable Units allow operators to replace key components without waiting for a technician
• Imaging System: 40-beam VCSEL laser for ultra-accurate color registration and fine detail
• Modular Finishing:
  • Saddle-stitch booklet finisher with edge trimming
  • High-capacity 5,000-sheet stacker with trolley cart
  • Z-folding and multi-hole punching units

Connectivity and Security

• Network Interface: Ethernet 10/100/1000 Base-T (Standard), USB 2.0
• Controller Options: Choice of integrated GWNX controller or advanced external EFI Fiery controllers
• Security: Standard HDD data oversight and administrative password management
• Power Requirements: 208V - 240V, 20A (Requires dedicated production-grade circuit)

Physical Dimensions

• Width: Approximately 1,320 mm (52 in.)
• Depth: Approximately 1,100 mm (43.3 in.)
• Height: Approximately 1,460 mm (57.5 in.) (Main Body)
• Weight: Approximately 415 kg (915 lb)
• Status: Landmark digital production system known for high resolution and professional finishing
