Xerox AltaLink C8170 Parts & Supplies

The Xerox AltaLink C8170 is a high-performance color multifunction printer designed for large workgroups and high-volume environments that require speed, reliability, and advanced finishing options. Built on Xerox ConnectKey Technology, it functions as a digital workplace assistant, offering an intuitive 10.1-inch tablet-like interface, comprehensive security with McAfee Embedded Control, and seamless cloud integration to maximize organizational productivity.

Core Performance Specifications

• Print Speed: Up to 70 ppm (pages per minute) for both color and black & white.
• First-Copy-Out Time: As fast as 4.0 seconds for color; 3.0 seconds for black & white.
• Resolution: Up to 1200 x 2400 dpi for exceptional color detail and crisp text.
• Monthly Duty Cycle: Up to 300,000 images per month.
• Processor/Memory: 1.9 GHz Intel® Atom™ Quad Core processor with 8 GB system memory and 128 GB SSD standard.

Paper Handling and Media

• Standard Paper Capacity: 3,140 sheets (Two 520-sheet trays, 100-sheet bypass, and a 2,000-sheet high-capacity tandem tray).
• Maximum Paper Capacity: Up to 6,140 sheets with optional high-capacity feeder.
• Media Weights: Supports up to 300 gsm.
• Maximum Sheet Size: Standard trays up to 12" x 18" (SRA3); Bypass tray supports banner printing up to 12.6" x 52".
• Document Feeder: Single-Pass Duplex Automatic Document Feeder (DADF) with 250-sheet capacity.

Scanning and Copying Features

• Integrated Scanner: Ultra-high-speed single-pass duplex scanning.
• Scan Speed: Up to 270 ipm (images per minute) in duplex mode.
• Scan Destinations: Scan to USB, Email, Network (FTP/SMB), and Cloud (Google Drive, OneDrive, Dropbox).
• OCR: Standard Optical Character Recognition for creating searchable and editable digital documents.
• Finishing Options: Supports a wide range of professional finishers for stapling, hole punching, and booklet making.

Connectivity and Security

• Connectivity: 10/100/1000Base-T Ethernet, High-Speed USB 2.0, NFC, Bluetooth (iBeacon).
• Mobile Readiness: Apple AirPrint, Mopria Certified, and Xerox Workplace App support.
• Security Features: McAfee Embedded Control, Whitelisting, AES 256-bit encryption, Disk Overwrite, and Cisco TrustSec integration.
• Technology: Built on Xerox ConnectKey Technology with access to the Xerox App Gallery.

Physical Dimensions:

• Base Dimensions: 24.4" W x 31.2" D x 46.0" H (620 x 793 x 1169 mm).
• Weight: Approximately 352 lbs (160 kg).
