Xerox Color 1000 Press Parts & Supplies

The Xerox Color 1000 Press is a high-speed digital color press engineered for the most demanding production environments. Delivering a blistering 100 pages per minute regardless of media weight, it is designed to maximize throughput for high-volume commercial print jobs. Featuring a 2400 x 2400 dpi resolution and the unique ability to apply clear dry ink for spot and flood gloss effects, the 1000 Press allows print providers to produce high-value marketing materials with exceptional detail and visual impact. Its robust duty cycle and advanced automation make it a cornerstone for businesses requiring reliable, high-capacity color production.

Core Performance Specifications

• Print Speed: Up to 100 ppm Letter/A4 for all supported media weights (55 to 350 gsm).
• Resolution: 2400 x 2400 dpi for breathtaking image detail and color depth.
• Monthly Duty Cycle: Up to 1,750,000 pages per month.
• Recommended Monthly Volume: 150,000 to 400,000 pages.
• Technology: Uses Low Melt EA Dry Ink for a consistent, oil-free matte finish.

Paper Handling and Media

• Standard Paper Capacity: 4,000 sheets (Two 2,000-sheet internal trays).
• Maximum Paper Capacity: Up to 8,000 sheets with optional Oversized High Capacity Feeder.
• Media Weights: Professional handling from 55 gsm to 350 gsm at full rated speed.
• Maximum Sheet Size: Up to 13" x 19.2" (330 x 488 mm).
• Auto-Duplexing: Standard high-speed automatic two-sided printing.

Scanning and Copying Features

• Integrated Scanner: Optional high-speed production scanner available.
• Specialty Effects: Optional 5th station for Clear Dry Ink to produce dimensional or high-gloss effects.
• Registration: Industry-leading front-to-back registration within +/- 0.5 mm.
• Finishing Options: Modular support for high-capacity stackers, professional booklet makers, and SquareFold trimmers.

Connectivity and Security

• Digital Front Ends (DFE): Supports high-performance Xerox FreeFlow® or EFI Fiery® EX/EX-P print servers.
• Connectivity: Standard Gigabit Ethernet for rapid data transfer in production environments.
• Security Features: Secure job management, data encryption, and secure network communication standards.

Physical Dimensions:

• Base Dimensions: Approximately 110" W x 43" D x 74" H (Engine).
• Weight: Approximately 2,200 lbs (1,000 kg).
