Xerox Nuvera 288 Parts & Supplies

The Xerox Nuvera 288 is the flagship high-speed monochrome digital production press of the Nuvera family, designed for the most intensive transactional printing and publishing environments. Utilizing a unique "Perfecting" tandem architecture, it features two high-performance print engines working in sync to deliver a blistering 288 duplex pages per minute. This innovative design ensures maximum productivity for double-sided document production without the mechanical complexity of traditional duplexing units. The Nuvera 288 utilizes Xerox's premier EA (Emulsion Aggregation) fine particle toner and advanced VCSEL imaging to produce surgical precision in text and high-definition monochrome graphics. With its robust 7.8-million impression monthly duty cycle, high-capacity vacuum-feed paper handling, and expansive suite of professional finishing options—including inline glue binding and high-capacity stacking—the Nuvera 288 serves as an indispensable powerhouse for producing high-quality monochrome books, statements, and direct mail with unmatched speed and 24/7 reliability.

Core Performance Specifications

• Device Type: High-Volume Monochrome Perfecting Production Press (Print Only)
• Architecture: Tandem Dual-Engine (Two 144 ppm engines working in sync)
• Rated Speed: 288 ipm (A4 / 8.5" x 11" Duplex); 144 ipm (11" x 17" / A3 Duplex)
• Print Resolution: 4800 x 600 dpi
• RIP Resolution: 1200 x 1200 dpi
• Monthly Volume: 3,000,000 images (Recommended) / 7,800,000 (Duty Cycle)
• Toner Technology: EA (Emulsion Aggregation) fine particle toner
• Controller: FreeFlow® Print Server with production-grade job management

Paper Handling and Media

• Standard Paper Capacity: 5,800 sheets (Base 2-module configuration)
• Maximum Paper Capacity: Up to 23,200 sheets (with multiple feed modules)
• Feeding Technology: Professional Vacuum-feed air-assist system for maximum reliability
• Media Sizes: 5.5" x 8.3" up to 12.6" x 19.3" (SRA3+)
• Paper Weight: 12 lb. Bond to 110 lb. Cover (44 to 300 g/m²)
• Registration Accuracy: TELER Registration ensures +/- 0.65 mm image-to-sheet precision

Image Processing and Finishing

• Pass-Through Mode: Allows continuous operation at half speed if one engine requires service
• Technology: Cyclone Cleaning Technology for high-fidelity monochrome reproduction
• Sheet Enhancement: Sheet Enhancement Module (SEM) for professional in-line de-curling
• Professional Finishing:
  • High-capacity 5,000-sheet stackers with roll-away carts
  • Inline Perfect Binder, Plockmatic booklet makers, and GBC FusionPunch
  • Tape Binder for thermal-bound documents

Connectivity and Security

• Network Interface: Ethernet 10/100/1000 Base-T, High-speed USB
• Supported Data Streams: Adobe PostScript 3, PDF, PCL, native IPDS and LCDS
• Power Requirements: Dual 187 - 240 VAC, 50 Amp, 50/60 Hz (Dedicated production power required)

Physical Dimensions

• Width: Approximately 4,400 mm (173 in.) (Typical configuration)
• Depth: Approximately 737 mm (29 in.)
• Height: Approximately 1,560 mm (61 in.)
• Weight: Approximately 2,250 kg (4,960 lb) (Fully configured)
• Status: The premier solution for high-volume monochrome transactional and publishing production
