Xerox PrimeLink C9265 Parts & Supplies

The Xerox PrimeLink C9265 is a high-performance color digital press designed for commercial print centers and production hubs requiring rapid document production and professional-grade color fidelity. delivering up to 65 pages per minute, it features Xerox's sophisticated 2400 x 2400 dpi Ultra HD resolution for stunningly crisp text and high-definition graphics with exceptionally smooth highlights. The C9265 is distinguished by its incredible media latitude—supporting weights up to 400 gsm—and its focus on high-value embellishments through Xerox's Adaptive CMYK+ technology. featuring standard high-speed single-pass duplex scanning at up to 270 ipm and automatic duplexing on heavy stocks, the PrimeLink C9265 serves as a premier workplace hub for producing professional-quality catalogs, brochures, and variable-data campaigns with surgical precision and exceptional engine uptime.

Core Performance Specifications

• Device Type: High-Volume Color Production Press
• Print Speed: Up to 65 ppm (A4/Letter) / 32 ppm (A3/Ledger)
• Print Resolution: 2400 x 2400 dpi (Ultra HD)
• Monthly Duty Cycle: Up to 500,000 pages
• First Copy Out Time: Approximately 4.4 seconds (Monochrome) / 5.7 seconds (Color)
• Imaging Technology: Electrophotographic system with EA (Emulsion Aggregation) Toner
• Specialty Toners: Supports Adaptive CMYK+ for Gold, Silver, White, and Clear toners

Paper Handling and Media

• Standard Paper Capacity: 3,260 sheets (Standard configuration)
• Maximum Paper Capacity: Up to 7,260 sheets with optional POD decks
• Media Sizes: Up to 13" x 19.2" (SRA3); Banners up to 13" x 51" (1,300 mm)
• Paper Weight: 16 lb. Bond to 147 lb. Cover (52 to 400 g/m²)
• Efficiency: Designed for continuous-run reliability with high-capacity consumables
• Duplexing: Standard automatic duplexing on all supported weights up to 400 g/m²

Production and Workflow Features

• Scan Speed (Duplex): Up to 270 ipm (B&W and Color) at 300 dpi
• Scan Resolution: Up to 600 x 600 dpi
• User Interface: 10.1-inch Color multi-touch screen with smartphone-like usability
• Print Servers: Integrated Xerox Server; Optional EFI Fiery EX/EX-i Color Servers
• Finishing Support: Modular support for High-Capacity Stacking, Booklet Makers, and Creasing

Connectivity and Security

• Network Interface: Ethernet 10/100/1000 Base-T, High-speed USB 3.0
• Printer Emulations: Standard PCL 6, PCL 5e, PDF Direct; Optional Adobe PostScript 3
• Security: Standard McAfee Embedded Control, HDD Encryption, and Secure Print
• Management Tools: Compatible with Xerox CentreWare Web and Global Print Driver

Physical Dimensions

• Width: 1,574 mm (62.0 in.) (Main Engine + SPDF)
• Depth: 804 mm (31.6 in.)
• Height: 1,392 mm (54.8 in.)
• Weight: Approximately 263 kg (579.8 lb) (Main Engine)
• Sustainability: Energy Star certified; designed for energy-efficient production operation
