Xerox VersaLink B7100 Parts & Supplies

The Xerox VersaLink B7100 series (including the B7125, B7130, and B7135) is a high-performance monochrome digital multifunction printer designed for busy office workgroups requiring rapid throughput, reliability, and advanced digital workflow integration. Delivering up to 35 pages per minute, it features Xerox's standard "ConnectKey" technology and a tablet-like 7-inch color touch screen interface for exceptional user efficiency. The B7100 series is distinguished by its high-resolution 1200 x 1200 dpi engine and its high-speed single-pass duplex scanner, Providing an immediate hub for rapid document production and high-fidelity digital conversion. Featuring standard automatic duplexing and advanced security features—including McAfee Embedded Control—it serves as a sophisticated workplace assistant that effectively bridges the gap between paper documents and modern digital or cloud-based workflows with surgical precision and exceptional engine uptime.

Core Performance Specifications

• Device Type: Workgroup Monochrome MFP (Print, Copy, Scan Standard)
• Print/Copy Speed:
  • B7125: Up to 25 ppm
  • B7130: Up to 30 ppm
  • B7135: Up to 35 ppm
• Print Resolution: Up to 1,200 x 1,200 dpi
• Monthly Duty Cycle: Up to 153,000 pages (Model dependent)
• Memory/Storage: 4 GB RAM Standard / Optional 320 GB HDD
• Warm-up Time: Approximately 28 seconds

Paper Handling and Media

• Standard Paper Capacity: 620 sheets (520-sheet Tray + 100-sheet Bypass)
• Maximum Paper Capacity: Up to 5,140 sheets with optional units
• Document Feeder: Standard 130-sheet Single-pass Duplex Automatic Document Feeder (DADF)
• Media Sizes: A5 up to A3 (up to 11" x 17" Ledger)
• Paper Weight: 16 to 42 lb. Bond (Trays); up to 80 lb. Cover (Bypass)
• Duplexing: Standard automatic stackless duplexing

Scanning and Smart Features

• Scan Speed: Up to 80 ipm (Monochrome & Color) for both simplex and duplex
• Scan Resolution: Up to 600 x 600 dpi
• User Interface: 7-inch tiltable color touchscreen with customizable icons
• Cloud Integration: Standard support for Google Drive, Dropbox, and OneDrive
• Smart Features: standard Xerox ConnectKey technology and searchable PDF creation

Connectivity and Security

• Network Interface: Ethernet 10/100/1000 Base-T, USB 3.0; Standard Wireless LAN
• Printer Emulations: PCL 6, PCL 5e, PDF Direct, XPS; Optional Adobe PostScript 3
• Security: Standard McAfee Whitelisting, AES-256 HDD Encryption, and TLS 1.3
• Fleet Management: Compatible with Xerox Quick Link and CentreWare Web

Physical Dimensions

• Width: 590 mm (23.2 in.)
• Depth: 670 mm (26.4 in.)
• Height: 766 mm (30.2 in.) (Main Body)
• Weight: Approximately 63 kg (138.9 lb)
• Sustainability: Energy Star compliant; designed for energy-efficient office operation
