Xerox Versant 80 Press Parts & Supplies

The Xerox Versant 80 Press is a high-performance digital production press designed for entry-to-mid-level production environments. It is celebrated for its Ultra HD Resolution and advanced automated image quality tools, providing print shops with a versatile and efficient solution for professional-grade printing.

Core Performance Specifications

• Print Speed: Up to 80 pages per minute (ppm) for 8.5" x 11" / A4 documents.
• Print Resolution: 2400 x 2400 dpi (VCSEL ROS imaging) with 1200 x 1200 x 10-bit rendering.
• Recommended Monthly Volume: 25,000 to 80,000 pages per month, with a duty cycle of up to 460,000 pages.
• Ultra HD Resolution: Combines high-resolution imaging with deep rendering for smooth gradients and sharp fine lines.
• Compact Belt Fuser: Ensures consistent image quality across a diverse range of media types, including synthetics and linens.

Paper Handling and Media

• Standard Capacity: 1,900 sheets, expandable to a maximum of 5,900 sheets.
• Media Weights: Supports weights from 52 gsm up to 350 gsm (uncoated and coated).
• Maximum Media Size: Up to 13" x 19.2" (330 x 488 mm).
• Toner Type: Utilizes Xerox® EA (Emulsion Aggregation) Low Melt Dry Ink for superior image quality and energy efficiency.
• Paper Sources: Multiple high-capacity feeding options available for long production runs.

Scanning and Copying Features

• Single-pass Duplex Automatic Document Feeder: High-speed scanning at up to 200 images per minute (ipm).
• Simple Image Quality Adjustment (SIQA): Includes automated tools for front-to-back registration, density uniformity, and image transfer.
• Modular Design: Supports a wide variety of finishing options, from basic stapling to full booklet creation.
• Digital Front Ends (DFEs): Compatible with Xerox® FreeFlow® Print Server or EFI™ Fiery® servers for precise color control.

Connectivity and Security

• Standard Connectivity: Integrated high-speed Ethernet for seamless network integration.
• Security Features: Standard security protocols including disk overwrite and data encryption to safeguard sensitive information.
• Performance Package (Optional): Maintains full print speed on all stocks up to 350 gsm and includes inline spectrophotometry for automated color calibration.

Physical Dimensions:

• Base Dimensions: Approximately 48" H x 33" W x 33" D (121.2 x 84.0 x 83.1 cm).
• Weight: Roughly 651 lbs (295 kg) for the base unit.
