Xerox WorkCentre 5024 Parts & Supplies

The Xerox WorkCentre 5024 is a robust monochrome A3 multifunction device designed to improve office productivity. With faster output speeds and expanded paper handling capabilities compared to entry-level models, it is an ideal solution for small to medium-sized businesses looking for a reliable workhorse for printing, copying, and scanning.

Core Performance Specifications

• Print Speed: Up to 24 ppm (A4) and up to 12 ppm (A3).
• Resolution: 600 x 600 dpi.
• Memory: 256 MB.
• First Copy Out Time: 7.2 seconds or less.
• Warm-up Time: Less than 19 seconds.
• Monthly Duty Cycle: Up to 25,000 pages per month.

Paper Handling and Media

• Standard Paper Capacity: 350 sheets (250-sheet tray + 100-sheet bypass tray).
• Maximum Paper Capacity: Up to 1,850 sheets with optional tray modules.
• Media Sizes: Supports media up to A3 (11 x 17") size.
• Auto-Duplexing: Optional Duplex Automatic Document Feeder (DADF) and duplex unit for two-sided output.
• Paper Weight: 60 to 90 gsm (Trays), 60 to 110 gsm (Bypass).

Scanning and Copying Features

• Scanning Capabilities: Standard color scanning to PC/Laptop via USB.
• Scan Resolution: Up to 600 x 600 dpi.
• Copy Features: ID Card Copy, N-up copying, and electronic sorting.
• Optional Fax: Super G3 faxing available with the optional fax kit.

Connectivity and Security

• Connectivity: Standard USB 2.0; optional 10/100Base-TX Ethernet for network printing and scanning.
• OS Support: Windows-based print and scan drivers.
• Energy Efficiency: ENERGY STAR qualified for reduced power consumption.

Physical Dimensions:

• Base Dimensions: 595 mm (W) x 573 mm (D) x 581 mm (H) (with DADF).
• Weight: Approximately 37 kg (with DADF).
