Xerox Versant 180 Press Parts & Supplies

The Xerox Versant 180 Press is a high-performance digital production press designed for mid-sized print shops and enterprise environments. It is renowned for its advanced automation, superior image quality, and versatility in handling a wide array of media types, making it an ideal choice for high-volume, professional-grade printing.

Core Performance Specifications

• Print Speed: Up to 80 pages per minute (ppm) for 8.5" x 11"/A4 documents.
• Print Resolution: 2400 x 2400 dpi VCSEL ROS (Ultra HD Resolution) for sharp, high-definition output.
• Recommended Monthly Volume: 80,000 pages, with a duty cycle of up to 750,000 pages per month.
• Ultra HD Resolution: Renders at 1200 x 1200 dpi with 10-bit depth for smooth gradients and crisp details.
• Performance Package (Optional): Maintains full 80 ppm speed on all stocks up to 350 gsm and includes an X-Rite® Inline Spectrophotometer for automated color calibration.

Paper Handling and Media

• Standard Capacity: 1,900 sheets, expandable up to a maximum of 9,900 sheets.
• Media Weights: Supports a broad range from 52 gsm up to 350 gsm (both coated and uncoated).
• Maximum Sheet Size: 13" x 19.2" (330 x 488 mm), with support for Extra Long Sheets (XLS) up to 13" x 26" (330 x 660 mm).
• Auto-Duplexing: Supports weights up to 300 gsm for automatic two-sided printing.
• High-Capacity Feeders: Optional Advanced High Capacity Feeders for extended run times.

Scanning and Copying Features

• Integrated Scanner: Dual-head color scanner with scanning speeds up to 200 images per minute (ipm).
• Simple Image Quality Adjustment (SIQA): Automates critical tasks such as image-to-media alignment, density uniformity, and image transfer.
• Advanced Finishing: Modular design supports various finishing options, including booklet makers, stackers, and folders.
• Scan Destinations: Scan to Email, Network, and USB for efficient document workflows.

Connectivity and Security

• Standard Connectivity: High-speed Ethernet and optional EFI Fiery® or Xerox® FreeFlow® Print Servers for advanced color management.
• Security Features: Standard encryption and disk overwrite features to protect sensitive production data.
• Page Description Languages: Supports Adobe PostScript 3, PDF, PCL, and more for seamless integration into existing workflows.

Physical Dimensions:

• Base Dimensions: Approximately 48" H x 30" W x 33" D (121.2 x 76.0 x 83.1 cm).
• Weight: Roughly 651 lbs (295 kg) for the base unit.
